Product description

SPECIFICATIONS

Brand Name: BIQU

Choice: yes

Communication method: CANBUS, USB

Expansion Interfaces: EndStop, I2C, Probe, RGB, PT100/PT1000, USB Interface, CAN Interface

Hign-concerned Chemical: None

Input Voltage: DC12V-DC24V 9A

Item Type: Motherboard

Logic Voltage: DC 3.3V

Microprocessor: ARM Cortex-M0 STM32F072C8T6 48MHz

Model: EBB36 EBB42 CAN

Model Number: EBB36 EBB42 CAN

Motor Drive: Onboard TMC2209 UART

Onboard Sensor: ADXL345

Origin: Mainland China

USB Communication Interface: USB-Type-C

Use for: CAN bus to connect Klipper expansion device

maximum output current: 5A

semi_Choice: yes
